Description
500W /600W /800W IP65 Waterproof Moving Head Beam Light Appearance Patented Original Customized Philips Bulb M-W800
LIGHT SOURCE
Light Source: Original Customized PHILIPS lamp(7500K~8500K)
Ballast: Original Customized PHILIPS
Average Life Span: ≥1500hours
POWER
Input Voltage: AC90~240V, 50/60Hz
Power Consumption: 500W/600W/800W
OPTICAL SYSTEM
Luminous Flux: 660000lumen@10m
Beam Angle: 0~1.2°
CRI: 85±5
PFC: ≥0.95
Frost: 1pc frost filter, can achieve soft light effect
Dimmer: 0~100% mechanical dimming, smooth without flicker
Shutter/Strobe: Independently strobe with double motors, 0.5~20 F.P.S, speed adjustable
Lens: Use imported multilayer coating lens combination, the diameter of beam aperture is up to 200mm
Projection Distance: Over 3000m in similar parallel light
MOVEMENT
Pan and Tilt: Use high precision 3-phase motors for pan and tilt, accurate location, smoothly moving, automatic correction location
Pan: 540°rotation, 8/16Bit adjustment
Tilt: 270°rotation, 8/16Bit adjustmentCOLOR SYSTEM
1 Color Wheel: Use Taiwan high temperature color filters, 11pcs colors+open, half color and rainbow effect
1 Rainbow Wheel: Use Taiwan filters, can project 1 or 8 beams of rainbow effectGOBOS
1 Fixed Gobo Wheel: 14pcs fixed metal gobos+open, bidirectionally shaking & flowing at variable speedCONTROL
Control Mode: DMX512, RDM function(remotely set the address code via a large DMX512 controller), Auto Run, Sound Control, Master\Slave and Manual
DMX Channels: 14/18CH
Lamp Control: Control the lamp on/off via controller
PHYSICAL
IP Grade: IP65
DMX Connector: 3-pin waterproof signal in and out XLR
Display: 2.8 inch colorful LCD screen, 180° inversion
LIGHT SOURCE
Light Source: Original Customized PHILIPS lamp(7500K~8500K)
Ballast: Original Customized PHILIPS
Average Life Span: ≥1500hours
POWER
Input Voltage: AC90~240V, 50/60Hz
Power Consumption: 500W/600W/800W
OPTICAL SYSTEM
Luminous Flux: 660000lumen@10m
Beam Angle: 0~1.2°
CRI: 85±5
PFC: ≥0.95
Focus: Motorized linear focus
1 Prism Wheel: 1pc 8-facet prism, bidirectionally rotating at variable speed (3-facet or 16-facet prism is optional)Frost: 1pc frost filter, can achieve soft light effect
Dimmer: 0~100% mechanical dimming, smooth without flicker
Shutter/Strobe: Independently strobe with double motors, 0.5~20 F.P.S, speed adjustable
Lens: Use imported multilayer coating lens combination, the diameter of beam aperture is up to 200mm
Projection Distance: Over 3000m in similar parallel light
MOVEMENT
Pan and Tilt: Use high precision 3-phase motors for pan and tilt, accurate location, smoothly moving, automatic correction location
Pan: 540°rotation, 8/16Bit adjustment
Tilt: 270°rotation, 8/16Bit adjustmentCOLOR SYSTEM
1 Color Wheel: Use Taiwan high temperature color filters, 11pcs colors+open, half color and rainbow effect
1 Rainbow Wheel: Use Taiwan filters, can project 1 or 8 beams of rainbow effectGOBOS
1 Fixed Gobo Wheel: 14pcs fixed metal gobos+open, bidirectionally shaking & flowing at variable speedCONTROL
Control Mode: DMX512, RDM function(remotely set the address code via a large DMX512 controller), Auto Run, Sound Control, Master\Slave and Manual
DMX Channels: 14/18CH
Lamp Control: Control the lamp on/off via controller
PHYSICAL
IP Grade: IP65
DMX Connector: 3-pin waterproof signal in and out XLR
Display: 2.8 inch colorful LCD screen, 180° inversion
Power Cable: Waterproof power cable
MATERIAL
Fixture Material: High hardness heat dissipation aluminum profile(die-casting aluminium), flame-retardant anti-aging high temperature engineering PVC, use outdoor imported fine sand s
