Description
personal design 10W-15W RGB full color ILDA animation laser light L-812B
Product name: 10W full color animation laser light L-812B10
Light source brand: Nichia (imported from Japan)
Light source power ratio:
Red: 3W@638nm Green: 3W@520nm Blue: 4W@450nm
Power supply voltage: 110-240v; 50/60 Hz
Laser color: full color
Divergence angle: <1.5mrad
Modulation mode: analog modulation/TTL modulation
Beam Angle: Max50°
Scanning speed: 25K
Laser show: text/pattern/animation/beam/LOGO/
Cooling method: air cooling
Lens reflectivity: ＞99%
Software control: American Pangolin (QS)
Working temperature: -20-45 degrees;
Control options: ILDA standard/sound control/self-propelled/DMX512/master-slave
Product name: 15W full color animation laser light L-812B15
Light source brand: Nichia (imported from Japan)
Light source power ratio:
Red: 4W@638nm Green: 5W@520nm Blue: 6W@450nm
Power supply voltage: 110-240v; 50/60 Hz
Laser color: full color
Divergence angle: <1.5mrad
Modulation mode: analog modulation/TTL modulation
Beam Angle: Max60°
Scanning speed: 30K
Laser show: text/pattern/animation/beam/LOGO/
Cooling method: air cooling
Lens reflectivity: ＞99%
Software control: American Pangolin (QS)
Working temperature: -20-45 degrees;
Product name: 10W full color animation laser light L-812B10
Light source brand: Nichia (imported from Japan)
Light source power ratio:
Red: 3W@638nm Green: 3W@520nm Blue: 4W@450nm
Power supply voltage: 110-240v; 50/60 Hz
Laser color: full color
Divergence angle: <1.5mrad
Modulation mode: analog modulation/TTL modulation
Beam Angle: Max50°
Scanning speed: 25K
Laser show: text/pattern/animation/beam/LOGO/
Cooling method: air cooling
Lens reflectivity: ＞99%
Software control: American Pangolin (QS)
Working temperature: -20-45 degrees;
Control options: ILDA standard/sound control/self-propelled/DMX512/master-slave
Product name: 15W full color animation laser light L-812B15
Light source brand: Nichia (imported from Japan)
Light source power ratio:
Red: 4W@638nm Green: 5W@520nm Blue: 6W@450nm
Power supply voltage: 110-240v; 50/60 Hz
Laser color: full color
Divergence angle: <1.5mrad
Modulation mode: analog modulation/TTL modulation
Beam Angle: Max60°
Scanning speed: 30K
Laser show: text/pattern/animation/beam/LOGO/
Cooling method: air cooling
Lens reflectivity: ＞99%
Software control: American Pangolin (QS)
Working temperature: -20-45 degrees;
Control options: ILDA standard/sound control/self-propelled/DMX512/master-slave
